Colour Laser Multifunctional

Print, Copy, Scan, Send, Store, Fax

1.8GHz Dual Core Processor

10.1" TFT LCD WSVGA Colour Flat-panel

Main CPU Side: 2 GB

Image Processing CPU Side: 1 GB + 512 MB

256 GB

Network: 1000Base-T/100Base-TX/10Base-T

Optional: Wireless LAN Board-D1 (IEEE 802.11 b/g/n)

Standard: USB 2.0 x1 (Host), USB 3.0 x1 (Host), USB 2.0 x1 (Device)

Optional: Serial Interface, Copy Control Interface

Standard: 650 Sheet

Maximum, 2,300 Sheets

Standard: 550-sheet Paper Cassette, 100-sheet Multi-Purpose Tray

Optional: 550-sheet Paper Cassette (CASSETTE MODULE-AE1), 550-sheet Paper Cassette with cabinet (CASSETTE FEEDING UNIT-AJ1), Triple 550-sheet Paper Cassettes (CASSETTE FEEDING UNIT-AK1)

Standard: 250 Sheets

Maximum: 500 Sheets (with STAPLE FINISHER-Z1)

Standard: Collate, Group

With External Finisher: Collate, Group, Offset, Staple

Multi-Purpose Tray: Thin, Plain, Heavy, Recycled, Colour, Transparency, Pre-punched, Bond, Label, Envelope Paper

Cassette: Thin, Plain, Heavy, Recycled, Colour, Pre-punched, Bond, Envelope

Standard Size: Legal, Letter, Executive, Statement

Custom Size: 3-7/8" x 5-7/8" to 8-1/2" x 14" (98.0 x 148.0 mm to 216.0 x 355.6 mm)

Envelopes: COM10 No.10, Monarch, DL, ISO-C5 Envelope

Custom Size: 3-7/8" x 5-7/8" to 8-1/2" x 14" (98.0 x 148.0 mm to 216.0 x 355.6 mm)

Paper Cassette Standard size: Legal, Letter, Executive, Statement

Custom Size : 3-7/8" x 7-1/2" to 8-1/2" x 14" (98.0 x 190.5 mm to 216.0 x 355.6 mm)

Envelopes: COM10 No.10, Monarch, DL, ISO-C5

Cassettes: 16 lb. Bond to 60 lb. Cover (60 to 163 g/m2)

Multi-Purpose Tray: 16 lb. Bond to 80 lb. Cover (60 to 220 g/m2)

Duplexing: 16 lb. Bond to 60 lb. Cover (60 to 163 g/m2)

Up to 36 ppm (Letter)

Up to 29 ppm (Legal)

From Power On: Approx. 10 Seconds

From Sleep Mode: Approx. 10 Seconds

Quick Startup Mode: Approx. 4 Seconds (time from device power-on to when copy jobs can be programmed).

Standard (Desktop): 20-1/2" x 25-7/8" x 25-1/8" (519 mm x 658 mm x 638 mm)

Basic: 33-1/2" x 35-3/4" (852 mm x 908 mm) (with Paper Cassette Open + Multi-Purpose Tray Extended)

Fully Configured: 55-3/8" x 35-3/4" (1407 mm x 908 mm) (with Staple Finisher-Z1 + Paper Cassette Open + Multi-Purpose Tray Extended)

Standard (Desktop): Approx. 108 lb. (49 kg)

1200 x 600

UFR II, PCL®6, Adobe® PS® 3

PDF, TIFF, JPEG, EPS, XPS

A range of standard and optional software and MEAP based solutions (including AirPrint, Mopria, Google Cloud Print, Canon PRINT Business, and uniFLOW Online) are available to provide printing from mobile devices or internetconnected devices and cloud-based services depending on your requirements. Please contact your sales representative for further information.

PCL: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T (Japanese, Korean, Simplified and Traditional Chinese), Barcode Fonts

PS: 136 Roman

UFRII/PS: Windows® 8.1/10/11/Server 2012/Server 2012 R2/Server 2016/Server 2019/Server 2022, Mac OS (10.12 or later)

PCL: Windows® 8.1/10/11/Server 2012/ Server 2012 R2/Server 2016/Server 2019/ Server 2022

PS: Windows® 8.1/10/11/Server 2012/Server 2012 R2/Server 2016/Server 201

As fast as 5.1 seconds (BW)/6.9 seconds (Colour)

With Platen: 600 x 600

With DADF: 300 x 600

Up to 999 copies

25%-400% (1% Increments)

25%, 50%, 64%, 78%, 100% (1:1), 129%, 200%, 400%

Single-pass Duplexing Automatic Document Feeder

Up to 100 Sheets (20 lb. Bond)

Legal, Letter, Statement

Custom Size: 1-7/8" x 5" to 8-1/2" x 14" (48.0 mm x 128.0 mm to 216.0 mm x 355.6 mm)

Business Card: 1-7/8" x 3-3/8" to 2-1/8" x 3-5/8" (48.0 mm x 85.0 mm to 55.0 mm x 91.0 mm)

One-Sided Scanning: 13.3 to 34 lb. Bond (50 to 128 gsm) (BW), 17 to 34 lb. Bond (64 to 128 gsm) (CL)

Two-Sided Scanning: 13.3 to 34 lb. Bond (50 to 128 gsm) (BW), 17 to 34 lb. Bond (64 to 128 gsm) (CL)

Business Card: 21.3 lb bond to 80 lb cover (80 to 220 gsm)

Sheet, Book, 3-Dimensional Objects [Up to 4.4 lb. (2 kg)]

Colour Network ScanGear2 for both Twain and WIA

Supported OS: Windows® 8.1/10/11/Server 2012/ Server 2012 R2/Server 2016/ Server 2019/Server 2022

Scan for Copy: 600 x 600

Scan for Send: (Push) 600 x 600 (SMB/FTP/WebDAV/IFAX), (Pull) 600 x 600

Scan for Fax: 600 x 600

A range of solutions is available to provide scanning to compatible mobile devices and certain cloud-based services depending on your requirements.

Send:

Automatic Colour Select "OFF" (300 x 300 dpi):

• Single-Sided Scanning: 100 ipm
• Double-Sided Scanning: 200 ipm

Automatic Colour Select "ON" (300 x 300 dpi):

• Single-Sided Scanning: 50 ipm
• Double-Sided Scanning: 100 ipm

Copy:

Scan Speed priority (300 x 600 dpi):

• Single-Sided Scanning: 50 ipm
• Double-Sided Scanning: 100 ipm

Image Quality priority (600 x 600 dpi):

• Single-Sided Scanning: 30 ipm
• Double-Sided Scanning: 50 ipm

Email/Internet Fax (SMTP), SMB v3.0, FTP, WebDAV, Mail Box, Super G3 Fax, IP Fax (Optional)

LDAP (2,000)/Local (1,600)/Speed Dial (200)

Push: Up to 600 x 600

Pull: Up to 600 x 600

File: FTP (TCP/IP), SMB v3.0, WebDAV

Email: SMTP, POP3

TIFF, JPEG, PDF (Compact, Searchable, Apply policy, Optimize for Web, PDF A/1-b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word)

2

Super G3: 33.6 Kbps

G3: 14.4 Kbps

MH, MR, MMR, JBIG

400x400 (Ultra Fine), 200x400 (Super Fine), 200x200 (Fine), 200x100 (Normal)

Statement to Legal

Up to 30,000 Pages (2,000 jobs)

Max. 200

Max. 199 Dials

Max. 256 Addresses

Yes

100 User In-boxes, 1 Memory RX Inbox, 50 Confidential Fax In-boxes, Maximum 10,000 Pages (2,000 jobs) Stored

Communication Protocol: SMB or WebDAV

Supported Client PC: Windows (Windows 8.1/10)

Concurrent Connections (Max.)

• SMB: 64
• WebDAV: 3 (Active Sessions)

Approx. 16 GB

Standard: Universal Login Manager, uniFLOW Online Express (no charge for this solution; however activation is required), User Authentication, Department ID Authentication, Access Management System, Device and Function Level Log-in

Optional: uniFLOW

Standard: Protecting SSD Data (SSD Data Encryption (FIPS140-2 Validated), SSD Data Overwrite Erase, SSD Lock), Standard SSD Initialize, Trusted Platform Module (TPM), Job Log Conceal Function, Checking MFP Software Integrity (Verify System at Startup, Runtime Intrusion Detection), Automatic Recovery, Common Criteria Certification (IEEE2600.2/HCD-PP)

Optional: IEEE 2600.2 Common Criteria Certification, Data Loss Prevention (Requires uniFLOW)

Standard: TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Disabling Unused Functions (Enabling/Disabling Protocols/ Applications, Enabling/Disabling Remote UI, Enabling/Disabling USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Space in the MFP, Scan and Send-Virus Concerns for E-mail Reception

Standard: Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print14 ), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, Adobe LiveCycle® Rights Management ES2.5 Integration), BOX Security (Mail Box Password Protected, Advanced Space Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/ Restrict Fax Driver Transmissions, Allow/ Restrict Sending from History, S/MIME Support), Document Tracking (Secure Watermark)

Optional: User Signatures

Temperature: 50 to 86 ºF

Humidity: 20 to 80% RH (Relative Humidity)

110-127V AC 60 Hz, 6.9 A

NEMA 5-15P

Maximum: Approx. 1,500 W

Sleep Mode: Approx. 0.8 W or Less

Typical Electricity Consumption (TEC) Rating: 0.32 kWh

ENERGY STAR® Certified

GPR-58 Toner BK/C/M/Y

Black: 23,000 Pages

Colour (C,M,Y): 18,000 Pages
