| Print head |
On-demand piezo head (2 staggered layout) |
| Print resolution |
Y: 600, 1200 dpi X: 600, 1200, 1800 dpi |
| Print gap |
By manual 3 levels (2.0/2.5/3.0 mm) |
| Ink |
Type/Color |
LUS-170：C,M,Y,K,Lc,Lm,W,Cl
LUS-175：C,M,Y,K,Lc,Lm,W,Cl *1
LUS-200：C,M,Y,K,W (Plan to support 2023 winter)
LUS-190：C,M,Y,K,W (Plan to support 2024 spring) *1
LUS-210：C,M,Y,K,W (Plan to support 2024 spring) *1 |
| Capacity |
1L bottle |
| Ink circulation |
Circulation in damper MCTv2 |
| Maximum print width |
1,360mm (53.5″) |
|
| Media |
Maximum width |
1,370mm (53.9″) |
|
| Thickness |
1 mm or lower |
| Roll diameter |
φ250 mm or less |
| Mountable no. |
Standard : 1 roll / Option : 3 rolls (with the Media changer) |
| Roll weight |
One roll：Max. 45 kg (99.2 lb) or less
Three rolls：Total 90 kg (198.4 lb) or less |
| Roll inside diameter |
2 inch / 3 inch |
| Media cutting |
Auto cutting by cutter of head unit *2 |
| Cutting function |
Cutting speed |
Max. 300 mm/s |
| Acceleration |
Max. 0.5G |
| Cutting pressure |
10 – 450 gf |
| Cutter response times |
10 times/sec |
| Repeatability |
±0.2 mm (Excluding shrinkage / expansion caused by the film temperature) |
| Interface |
Ethernet 1000 BASE-T (Recommended) / USB2.0 Hi-speed |
| Certifications |
VCCI class A, FCC class A, ETL IEC 62368-1,
CE Marking (EMC, Low voltage, Machinery directive, and RoHS),
CB, REACH, Energy Star, RCM, KC, UKCA |
| Power supply |
Single phase AC100-120V±10% /12A or
Single phase AC200-240V±10% /6A
50/60Hz±1Hz |
| Power consumption |
Max.1,440W or less Ă—1 / 800W (Continuous operation) / 4.5W or less (Sleep mode) |
| Operational environment |
Temperature: 20–30 °C (68–86 °F)
Humidity: 35–65% Rh (Non condensing)
Recommended temperature: 20–25 °C (68–77 °F)
Dust level: General office level |
| Dimensions (W x D x H) |
2,640 x 800 x 1,480mm
(103.9 x 31.5 x 58.3″) |
|
| Machine weight |
217kg (478.4 lb) |
|
